Customized Pressing Stainless Steel Dished Ellipsoidal Heads with Sand Blasting Finish

Name: Customized Pressing Stainless Steel Dished Ellipsoidal Heads with Sand Blasting Finish
Brand: Mingyi Machinery (Tianjin) Co., Ltd
SKU: MY027
Price: Negotiable USD
Availability: InStock

All Products

Dished Tank Heads
(604)

Elliptical Dished Head
(66)

Industrial Pipe Valve
(735)

Industrial Storage Tank
(89)

Industrial Gelatin Equipment
(21)

Water Manhole Cover
(5)

Certification

I'm Online Chat Now

Customized Pressing Stainless Steel Dished Ellipsoidal Heads with Sand Blasting Finish

Large Image : Customized Pressing Stainless Steel Dished Ellipsoidal Heads with Sand Blasting Finish

Product Details:

Place of Origin:	Tianjin, China
Brand Name:	mingyi
Model Number:	MY027

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$30.00/sets >=10 sets
Packaging Details:	wooden case
Supply Ability:	10000 Set/Sets per Month

Contact Now

Customized Pressing Stainless Steel Dished Ellipsoidal Heads with Sand Blasting Finish

Description

Warranty:	1 Years	Customized Support:	OEM, ODM, OBM
Technics:	Pressing	Shape:	Equal
Head Code:	Circle	Product Name:	Pipe Fitting
Application:	Industry	Standard:	ASME
MOQ:	1 Piece	OEM:	Avaiable
Keyword1:	Tank Head	Surface Treatment:	Sand Blasting
Feature:	High Precision	Size:	Customized Size
Usage:	Pipe Quick Easy Pipe Repair Clamp	Port:	Tianjin,china

Recommend Products

Products Description

ASME Flanged Dished Head Dished Flared Flanged Head Dished Only Head Standard Flanged Dished Head

Conical Head Hemi Head Reversed Flanged Dished Head Flanged Only Head

Characters

1. All heads manufactured from Stainless Steel and other Nickel Alloys
2. All available polished ID/OD from 80 Grit to 400 Grit (less than 5 RA.)
3. Heads manufactured as ID, OD and any other dimension between whole numbers
4. Weld Preps include: Square Edge, ID or OD Bevel, ID/OD Bevel, ID or OD Bevel with land, ID/OD Bevel with Land, ID or OD Tapers with Bevel and Land.

Product Details

1. Hard Materials

Temperature and pressure resistance, corrosion resistance

2. Strong resistance to pressure

Made of high-quality steel, strong pressure resistance

3. Long use time

Not easy to rust, long use time, suitable for a variety of working environments

4. Various specifications

Various types of tank heads can be customized according to customer requirements.

Product Paramenters

_Item		_{Torispherical / Ellipsoidal Dished Heads}
_Diameter		_{89-10000 mm}
_Thickness		_{2-300 mm}
_{Reduction Ratio}		_{About 10%}
_Material		_{Carbon steel (Q235,Q245,Q235R,Q245R,Q345B)} _{stainless steel (304,321,304L,316,316L), etc} _{According to customers’ requirement.}
_Technology		_{Hot pressing/cold pressing}
_{Surface Treatment}		_{Sandblasting/pickling/polishing}
_Test		_{UT,RT,MT,PT,ET}
_{Applicable Standard}		_{ANSI, ASME ,MSS, API, DIN, JIS, BS. AWWA and GB}
_Certificate		_{ISO9001 ,ISO14001,OHSAS18001}
_Applications		_{Mainly used in petroleum, electronics, chemical industry, medicine, textile, food, machinery, construction, nuclear power,}aerospace, military and other industries.
_Connection		_Butt-welding

Company Profile

Our company can make dish heads, flanges, assemblies and other products. In addition, we also provide CNC processing services and panel processing services. Our integrity, strength and product quality have been recognized by the industry!

1. Guarantee： We guarantee all products for one year.

2. 24 Hours Online: Patiently answer your questions.

3. Remote Service: Remote service is available.

4. Quick Response： Provide solutions for troubles within 12 hours.

5. Spare Parts: Fast delivery worldwide for original spare parts.

6. Customization: Customized solutions for diverse products.

* Before production, we will send the drawing of the product according to your requirements.

* During the production process, we will regularly send you the production situation and pictures.

* We will test the product before shipment and send you the photo and video.

Exhibition Site

Lots of our products have obtained patent certificates and they have been sold to Europe, Australia, USA, Chile, Russia and other countries. Our products have good impression on all of customers, it helps clients to save lots of manpower. The machinery also improve efficiency a lot, workers love them very much!With good product quality and business reputation, we are deeply supported and loved by customers!

Certifications

If the quantity of order is not very big,we could send them to you by express deliverysuch as TNT,DHL,UPS or EMS etc.

If order is big.we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term cooperated agent also available.

FAQ

Q: What's your advantage?

A: Honest business with competitive price and professional service on export process.

Q: Can you give warranty of your products?

A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.

Q: What's the information should I provide when inquiry?

A: Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.

Q: How about your delivery time?

A: Generally, it will take 15 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q: How do you ensure the quality of products?

A: Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.

Q: How do you make our business long-term and good relationship?

A: We keep good quality and competitive price to ensure our customers benefit ;We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
