Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual

Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual

Large Image :  Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual

Product Details:
Place of Origin: Tianjin, China
Brand Name: MINGYI
Model Number: MINY49-1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $13,000.00/sets 1-4 sets
Packaging Details: wooden case
Supply Ability: 10 Set/Sets per Month
Contact Now

Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual

Description
Processing: Sterilizer Applicable Industries: Chemical Industry, Food
Showroom Location: Tianjin China Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Hot Product
Warranty Of Core Components: 1 Year Core Components: Engine
Condition: New Weight: 5000 KG, Depends On Specifications
Dimension(L*W*H): Customized Warranty: 1 Year
Color: Customized Size: Customized
Material: Steel Function: Sterilizeration
Name: Evaporative Sterilizer Certificate: Complete
Quality: High Quality Instructions: Reference Manual
After-sales Service: Support Port: Tianjin, China

Product Display
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 0
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 1
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 2
1. Product Parameters
Item
Model: XZMJ
XZMJ-600
XZMJ-1000
XZMJ-2000
Capacity
gelatin T/Y
1000
1500
3000
Feed rate
Kg/h
600
1000
2000
Inlet concentration
%
24
Outlet concentration
%
30
Sterilization
℃/sec
140°C/ 4-6 sec
evaporation
kg/h
120
200
400
Steam consumption
0.8mpa kg/h
200
340
660
Cooling water
35℃/45℃ m³/h
10
12
20
Power
kw
17.45
17.45
29.7

2. Product Description

This plant is unitized with an evaporator and sterilizer which has combined function of increase concentration and sterilization.Gelatirliquor are evaporated to higher concentration more than 30% by force circulating evaporator and then heated up to 140℃and maintained for 4-6 seconds in DSI unit.Capacity is 1000T-3000T gelatin per year,Accessories include:sterilization flash tank,Inlet balance tank,plate heater flash evaporator tank,condenser,pre-heaterT-type sterilizer, U-type holding tube.Feed pumpcirculation pumpoutlet pump of flash evaporator outlet pump of sterilizervacuum pumpframe structure,panel. The equipment is made of S.S.304
3. Production Progress
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 3
Related Products
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 4
Company Profile
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 5
Mingyi Intelligent Equipment ( Tianjin) Co.,Ltd. is a leading producer that integrates the research, design and customized development, production and sales services of gelatin equipment in China. We are the Chinese High Technology company, and has more than 40 national patents. We supply one-stop service for clients, including designing, full set of equipment for gelatin production line,process technology,testing and training, etc.with more than 20 years.
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 6
We cooperate with Tianjin University, Beijing University of Chemical Technology, Hebei University of Technology and other universities in researching and developing the gelatin equipment. We always provide the most economical and efficient solutions for clients to maintain a sustainable business for the long-term. With good product quality, competitive price and business reputation,we are deeply supported and loved by clients.
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 7
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 8


Honesty and trustworthiness are the foundation of the company, and excellence is our pursuit. We hope to cooperate with you with lofty ideals to create abright future, welcome friends to come and guide! we are looking forward to do business with you.
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 9
Our Certificates
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 10
Our Customers
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 11
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 12
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 13
Package & Transport
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 14
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 15
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 16
FAQ
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 17
Q: Are you manufacturer or distributor? A: We are manufacturer and we have more than 20 years experience in the gelatin filed.
Q: Could you help us to build the gelatin factory? A: Yes, we can provide the one-stop service for building the gelatin factory, including factory designing, full set of equipment for gelatin production line, process technology, testing and training, etc.
Q: How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
Q: Do you sell only standard products? A: No, we are able to make the machines according to customers’ requirements, company also provides customized solutions and products for users.
Q: Do you have after sales support? A: Yes, we provide 1 year warranty, and have good after-sales policy. We need your machines running in order to keep business running.
Q: How do you make our business long-term and good relationship? A: We keep good quality and competitive price to ensure our customers benefit ;We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Customized Steel Air Autoclave Large Evaporative Sterilizer Machine Reference Manual 18
